FastTrace™ 2 Series Hardware Installation Manual

21790_05 59

Part

Amount + Reference Number

Flat cable (6 pins x 35 cm)

1 x #21760101

Flat cable (10 pins x 20 cm) for USB

1 x #16540260

Flat cable (10 pins x 30 cm) for audio

1 x #16540280

Reset cable

1 x #21760402

Part

Amount + Reference Number

Connector adapter for DG41TY and DH61BE

motherboards

1 x #16500660

Connector adapter for PH10LU motherboard

1 x #16500665

DG41TY: place the adapter on the AUDIO connector.

DH61BE: place the adapter on the USB connector.

PH10LU: place the adapter on the USB connector.
