B95W
Operation
07_Bedienung_en.fm - V1.0 - 1.8.17
245 / 306
7
26
Continuous operation - additional control circuit 1
Switch on continuous operation: Move the dial (3) integrated into the right
joystick to the right or left and hold it there, then press the front button on the
joystick (2).
Deactivating continuous operation: Press the button at the front of the joystick
(2) again or push dial (3) fully to the right or left until it reaches the stop.
Operating the
hammer
Set max. available oil volume for auxiliary control circuit 1 on the display.
J See chapter 5.3.4 “Display”.
Use the roller on the right-hand joystick (3) to control the hammer precisely.
Using the grab
(swing bucket
etc.)
Set required oil volume for auxiliary circuit 1 on the display.
J See chapter 5.3.4 “Display”.
Activate the auxiliary control circuit via the dial (3) on the joystick.
Notice
The mounting and operating instructions of the hydraulic rock breaker
manufacturer must be observed.
