B95W
Operation
256 / 306
7
07_Bedienung_en.fm - V1.0 - 1.8.17
26
Changing
procedure
using the quick-
attach system
Pick up the clam shell grab and close the quick-attachment system.
Fully retract the bucket cylinder piston rod and close the ball valves (3).
Connect the swivel motor to the couplings (1) - auxiliary control circuit - and
connect the “Open/Close” function to the bucket cylinder couplings (2).
Notice
When the grab has been dismantled, reopen the ball valves.
