YASKAWA A1000 HHP User Manual

Setting 2: Conveyor Application
Table 1.7 Conveyor: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Duty Rating 0: Heavy Duty
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 1.8 Conveyor: User Parameters (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
A1-02 Control Method Selection C1-02 Deceleration Time 1
b1-01 Frequency Reference Selection E2-01 Motor Rated Current
b1-02 Run Command Selection L3-04 Stall Prevention Selection during Deceleration
C1-01 Acceleration Time 1 − −
Setting 3: Exhaust Fan Application
Table 1.9 Exhaust Fan: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
b1-04 Reverse Operation Selection 1: Reverse Prohibited
C6-01 Duty Selection 1: Normal Duty
E1-03 V/f Pattern Selection 0FH
E1-07 Mid Output Frequency 30.0 Hz
E1-08 Mid Output Frequency Voltage 50.0 V
L2-01 Momentary Power Loss Operation Selection 1: Enabled
L3-04 Stall Prevention Selection during Deceleration 1: Enabled
Table 1.10 Exhaust Fan: User Parameters (A2-01 to A2-16)
No. Parameter Name No. Parameter Name
b1-01 Frequency Reference Selection E1-07 Mid Output Frequency
b1-02 Run Command Selection E1-08 Mid Output Frequency Voltage
b1-04 Reverse Operation Selection E2-01 Motor Rated Current
b3-01 Speed Search Selection at Start H1-05
Multi-Function Digital Input Terminal S5 Function
Selection
C1-01 Acceleration Time 1 H1-06
Multi-Function Digital Input Terminal S6 Function
Selection
C1-02 Deceleration Time 1 H1-07
Multi-Function Digital Input Terminal S7 Function
Selection
E1-03 V/f Pattern Selection L5-01 Number of Auto Restart Attempts
Setting 4: HVAC Fan Application
Table 1.11 HVAC Fan: Parameter Settings
No. Parameter Name Default Setting
A1-02 Control Method Selection 0: V/f Control
b1-04 Reverse Operation Selection 1: Reverse Prohibited
b1-17 Run Command at Power Up 1: Run command issued, motor operation start
C6-01 Duty Rating 1: Normal Duty
C6-02 Carrier Frequency Selection 1: 2.0 kHz
H2-03 Terminals P2 Function Selection 39: Watt Hour Pulse Output
1.1 A: Initialization
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
15
1
Parameter Details

YASKAWA A1000 HHP Specifications

General

Series	A1000
Overload Capacity	150% for 60 seconds
Horsepower	0.5-1000 HP
Control Method	V/f Control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Ground Fault
Communication	Modbus, DeviceNet, Profibus, Ethernet/IP
Input Voltage	200-240 V, 380-480 V
Output Voltage	0-Input Voltage
Frequency	400 Hz
Power Range	0.4-630 kW
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	5% to 95% RH (non-condensing)
Enclosure Rating	IP20, IP00
Voltage	200-480 V
