No.
(Addr.
Hex)
Name Description Values Page
F7-14
(3F2)
Duplex Mode Selection
All Modes
Selects duplex mode setting.
0: Half duplex forced
1: Auto-negotiate duplex mode and communication speed
2: Full duplex forced
Default: 1
Range: 0 to 2
–
F7-15
(3F3)
Communication Speed
Selection
All Modes
Sets the communication speed
10: 10 Mbps
100: 100 Mbps
Default: 10
Range: 10, 100
–
F7-16
(3F4)
Communication Loss
Timeout
All Modes
Sets the timeout value for communication loss detection in tenths of a second.
A value of 0 disables the connection timeout.
Example: An entered value of 100 represents 10.0 seconds.
Default: 0
Min.: 0
Max.: 300
–
F7-17
(3F5)
EtherNet/IP Speed Scaling
Factor
All Modes
Sets the scaling factor for the speed monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-18
(3F6)
EtherNet/IP Current Scaling
Factor
All Modes
Sets the scaling factor for the output current monitor in EtherNet/IP Class ID
2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-19
(3F7)
EtherNet/IP Torque Scaling
Factor
All Modes
Sets the scaling factor for the torque monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-20
(3F8)
EtherNet/IP Power Scaling
Factor
All Modes
Sets the scaling factor for the power monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-21
(3F9)
EtherNet/IP Voltage Scaling
Factor
All Modes
Sets the scaling factor for the voltage monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-22
(3FA)
EtherNet/IP Time Scaling
All Modes
Sets the scaling factor for the time monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-23 to
F7-32
(3FB to
374)
Dynamic Output Assembly
Parameters
All Modes
Parameters used in Output Assembly 116. Each parameter contains a
MEMOBUS/Modbus address. The value received for Output Assembly 116
will be written to this corresponding MEMOBUS/Modbus address. A
MEMOBUS/Modbus address value of 0 means that the value received for
Output Assembly 116 will not be written to any MEMOBUS/Modbus register.
Default: 0 –
F7-33 to
F7-42
(375 to
37E)
Dynamic Input Assembly
Parameters
All Modes
Parameters used in Input Assembly 166. Each parameter contains a
MEMOBUS/Modbus address. The value sent for Input Assembly 166 will be
read from this corresponding MEMOBUS/Modbus address. A MEMOBUS/
Modbus address value of 0 means that the value sent for Input Assembly 166
is not defined by the user, therefore the option default register value will be
returned.
Default: 0 –
<1> Parameter setting value is not reset to the default value when the drive is initialized.
<2> Cycle power for setting changes to take effect.
<3> If F7-13 is set to 0, all IP addresses (F7-01 to F7-04) must be unique.
A.8 F: Options
268
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
