YASKAWA A1000 HHP - Page 304

No.
(Addr.
Hex)
Name Description
Analog Output
Level
Unit
U4-23
(7DF)
Communication Option
Card Reference
All Modes
Displays drive control data set by an option card as a four-digit hexadecimal
number.
No signal output
available
–
U4-32
(7FB)
Motor Temperature (NTC)
All Modes
Displays the motor temperature (NTC).
U4-32 will display “20 °C” when a multi-function analog input is not set
for motor thermistor input (H1-oo = 17H).
No signal output
available
°C
U4-35
(1042)
UV Alarm Location
Monitor
All Modes
Displays the module where the UV alarm occurred as a binary number.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
No signal output
available
–
U4-36
(1043)
OV Alarm Location
Monitor
All Modes
Displays the module where the OV alarm occurred as a binary number.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
No signal output
available
–
U4-37
(1044)
oH Alarm Location
Monitor
All Modes
Displays the module where the oH alarm occurred as a binary number.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
Note: This parameter is only available in models CIMR-
Ao4A0930, 4A1200, and A1000 HHP.
No signal output
available
–
U4-38
(1045)
FAn Alarm Location
Monitor
All Modes
Displays the module where the FAn alarm occurred as a binary number.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
Note: This parameter is only available in models CIMR-
Ao4A0930, 4A1200, and A1000 HHP.
No signal output
available
–
U4-39
(1046)
voF Alarm Location
Monitor
All Modes
Displays the module where the voF alarm occurred as a binary number.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
Note: This parameter is only available in models CIMR-
Ao4A0930, 4A1200, and A1000 HHP.
No signal output
available
–
U4-41
(7FE)
UnbC Current Max
Location Monitor
All Modes
Displays the maximum UnbC current detected.
Bit 0: Axis 1
Bit 1: Axis 2
Bit 2: Axis 3
Bit 3: Axis 4
Bit 4: Axis 5
No signal output
available
0.10%
<1> When reading the value of this monitor via MEMOBUS/Modbus, a value of 8192 is equal to 100% of the drive rated output current.
<2>
The unit is 1 A in models CIMR-Ao4A0930 and 4A1200.
A.15 U: Monitors
304
YASKAWA ELECTRIC SIEP YEAHHP 01B YASKAWA AC Drive – A1000 HHP Programming Manual
