10.1 System Configuration Diagrams and Selection Tables
10.1.2 Selection Table
10
Cables and User-Assembled Wiring Materials for SERVOPACKs
10-9
*1. This Converter Cable is required to use the Σ-III-series Digital Operator (JUSP-OP05A) for Σ-7-series SERVO-
PACKs.
*2. This Converter Cable is required to prevent the cable from disconnecting from the Digital Operator.
*3. When using safety functions, connect this Cable to the safety function devices.
When not using safety functions, connect the enclosed Safety Jumper Connector (JZSP-CVH05-E) to the SER-
VOPACK.
*4. Use the Connector Kit when you make cables yourself.
