12.5 Noise Filter
12-26
 Σ-7W SERVOPACKs and Σ -7C SERVOPACKs
External Dimensions
 Model: HF3010C-SZC, HF3020C-SZC, or HF3030C-SZC
 Model: HF3050C-SZC-47EDD or HF3060C-SZC
Main
Circuit
Power
Supply
SERVOPACK
Order Number Specification Mass
Leakage
Current
Manufac-
turer
Inquiries
Maximum
Applicable Motor
Capacity [kW]
Model
SGD7W-
SGD7C-
Three-
phase,
200
VAC
0.2 1R6A HF3010C-SZC
Three-phase,
500 VAC,
10 A
1.0 kg
4 mA
200 VAC
/60 Hz
Soshin
Electric
Co., Ltd.
Yaskawa
Controls
Co., Ltd.
0.4 2R8A
HF3020C-SZC
Three-phase,
500 VAC, 20
A
1.4 kg0.75 5R5A
1.0 7R6A
Single-
phase,
200
VAC
0.2 1R6A HF2010A-UPF
Single-phase
250 VAC,
10 A
0.5 kg
1.2 mA
250 VAC
/60 Hz
0.4 2R8A
HF2020A-UPF
-2BB
Single-phase
250 VAC,
20 A
0.8 kg
3 mA
250 VAC
/60 Hz
0.75 5R5A
HF2030A-UPF
-2BB
Single-phase
250 VAC,
30 A
0.8 kg
78 ± 4
210 ± 2
220 ± 4
4.5 dia.
3 × M4
3 × M4
M4
R2.25 × 6
(12.5)(12.5)
(10.5)
55 ± 2
66 ± 4
Unit: mm
3
×
M5
R2.75
×
7
M4
3
×
M5
(16)(16)
(13)
260
±
2
270
±
4
70
±
2
80
±
4
84
±
4
5.5 dia.
Unit: mm
