YOKOGAWA DL9040L User Manual

6-40
IM 701310-01E
• 1080/60i, 1080/50i, and 1080/24sF Example 1080/60i, 1080/50i, and 1080/24sF Example
The line numbers below are for the case when the field number is set to 1.
(Numbers assigned sequentially with 565 set to 2 if the field number is set to 2.)
1120 1125
(1) 2 3 4 5 6 7 41
5H 5H 35H
517H45H
557 562 563 564 565 566 567 568 569 603
5H 5H 34H
518H45H
1/2H 1/2H
2245 2250
1126 1127 1128 1129 1130 1131 1132 1166
2251
1682 1687 1688 1169 1170 1171 1172 1173 1174 1728
Line numbers inside the parentheses cannot be set.
Field 2
Line number
Field 1
Line number
• 720/60p Example
750
(1) 2 3 4 5 6 7
5H 5H 20H
30H
2250
751 752 753 754 755 756 757
2251
8
758
Line numbers inside the parentheses cannot be set.
Line number
• 1080/25p, 1080/24p, and 1080/60p Example 1080/25p, 1080/24p, and 1080/60p Example
1125
(1) 2 3 4 5 6 7
5H 5H 35H
45H
2250
1126 1127 1128 1129 1130 1131 1132
2251
8
1133
Line numbers inside the parentheses cannot be set.
Line number
Frame Skip
This function is used to skip frames such as when the color burst is inverted every frame.
You can select the number of frames at which this operation is repeated.
1 Activates a trigger at the specified field every time.
2 Skips 1 frames and activates a trigger at the specified field of the succeeding frame. This
operation is repeated every 2 frames.
4 Skips 3 frames and activates a trigger at the specified field of the succeeding frame. This
operation is repeated every 4 frames.
8 Skips 7 frames and activates a trigger at the specified field of the succeeding frame. This
operation is repeated every 8 frames.
Note
Hold-off, trigger coupling, and HF rejection settings are ignored.
6.13 Setting the TV Trigger
