Explanation
You can set the following dialog box properties: translucent display; waveform display
colors; grid, zoom box, cursor, and marker brightness.
Translucent Display
When translucent display is turned ON, configuration dialog boxes are displayed
translucently, so the contents underneath it can be seen.
Waveform Display Colors and Brightness
• Waveform Display Color
• The waveform color of input waveforms CH1 to CH4,* reference waveforms REF1
to REF4, and computation waveforms MATH1 to MA
TH4 can be selected from 16
colors.
* If computation waveforms are assigned to input channels, CH1 to CH4 correspond to
MATH5 to MATH8, respectively. And, the colors of CH1 to CH4 are assigned to the
corresponding computation channels.
• This waveform color setting also applies to the title bar color of the menu that
appears when a channel key is pressed.
• Brightness of the Grid, Zoom Box, Cursor, and Marker
Y
ou can set the brightness of the grid, zoom box, cursor, and marker.
Selectable range: 0 to 31
Resetting
Press RESET to reset the waveform display color or the brightness of the grid, zoom
box, cursor, or marker to the default value.
8.8 Setting the Translucent Display, Waveform Display Colors, and Brightness
