10-46

IM 701310-01E

Displaying the Histogram

Selecting the Displayed Items

Press the Item soft key.

The menu that appears varies depending on the set waveform parameter mode

(see section 10.2 for details). Follow the instructions that correspond to the menu

that appears.

• If the mode is Basic, Continuous Statistics, or History Statistics, and you select Area 1 or

Area2, proceed to step 6.

• If the mode is Cycle Statistics and you select Basic, proceed to step 6.

• If the mode is Basic, Continuous Statistics, History Statistics, or Cycle Statistics and you

select Calc, proceed to step 8.

When the mode is Basic, Continuous

Statistics, or History Statistics

When the mode is

Cycle Statistics

The menu changes depending on the waveform parameter mode.

10.8 Displaying a Histogram, Trend, or List of the Automatically Measured Waveform Parameters
