15-14

IM 701310-01E

Note

For information about how to operate the keyboard (soft keyboard), see section 4.2.

Connecting to/Disconnecting from the Network Drive

11.

Press the Connect soft key.

The DL9000 is now connected to the network drive.

When pressing the

Disconnect

soft key, the DL9000 is disconnected.

Saving Screen Images and Saving/Loading Measurement/Setup Data

•

Saving the Screen Image Data

12.

Press the SHIFT+PRINT (MENU).

13.

Select a network drive with the rotary knob in the File Path setup.

The procedure is similar to that in section 13.8.

•

Saving/Loading Measurement Data/Setup Data

12.

Press FILE.

13.

Select a network drive with the rotary knob.

The procedure afterward is similar to those in sections 13.4 and 13.5.
