Ethernet Communications (Optional)
15-15
IM 701310-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
Explanation
As with the PC card drive, you can save screen image data, measurement data or setup
data to a network drive via the Ethernet network.
File Server
Enter the host name of file server (the PC running the file server) on the network to which
measurement/setup data will be saved. The IP address cannot be used to set up the file
server.
User Name
Enter a user name using up to 30 characters.
The characters that can be used are all the ASCII characters on the keyboard.
Password
Enter the password corresponding to the user name using up to 30 characters.
The characters that can be used are all the ASCII characters on the keyboard.
Note
• A shared service should be run on a personal computer to which the DL90001 is connected.
• To use this function, you must configure TCP/IP according to the procedure given in section
15.2.
• When the power is turned to ON, the connection to the file server is restored.
15.3 Saving and Loading Measurement/Setup/Image Data on a Network Drive
To Next Page
