Ethernet Communications (Optional)
15-25
IM 701310-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
Connecting a PC to the DL9000
Open a Web browser on a PC that is connected to the network.
In the browser’s address bar, enter “http://,” followed by the IP address of the DL9000.
If authentication has been enabled on the DL9000, a dialog box for entering the user name
and password appears. Enter the user name and password that you specified in steps 4
through 7.
On Models without the LXI Option (/C8 and /C10)
Close the browser
Stop updating
the screen
Set the screen update rate
Click here to display a menu for
setting the screen update rate.
You can set the update rate to
2, 5, 10, 30, or 60 s.
Take a screen capture
The entire screen is captured.
Start measurement
on the DL9000
Stop measurement
on the DL9000
Manually update
the screen
Start updating the screen
The display is updated
automatically at the rate
that you specified.
15.7 Using a PC to Monitor the DL9000 and Change Its Settings (Web Server)
To Next Page
