YOKOGAWA DL9040L User Manual

Ethernet Communications (Optional)
15-27
IM 701310-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
App
Index
• Security Settings
On the DL9000 Web page, click Security to display the security setup page.
Register the settings.
Reset changed settings.
Old password
New password
Re-enter new password
Authentication settings
ON: Enable authentication
OFF: Disable authentication
User name
The current security settings appear inside the browser window. You can change the
settings in the window. After you change the settings, click Registration to transmit
them to the DL9000. Click Reset to undo the changes that you made.
• Monitoring
On the DL9000 W
eb page, click Instrument Monitor to monitor the DL9000.
Close the browser
Stop updating the
screen
Set the screen update rate
Click here to display a menu
for setting the screen update rate.
You can set the update rate to
2, 5, 10, 30, or 60 s.
Take a screen capture
The entire screen is captured.
Start measurement
on the DL9000
Stop measurement
on the DL9000
Manually update
the screen
Show or hide the
connection status
Start updating the screen
The display is updated
automatically at the rate
that you specified.
15.7 Using a PC to Monitor the DL9000 and Change Its Settings (Web Server)
