Output Format
RTP
RTSP
UDP
TSRTP
TSFILE
RTMP
RTMPS
SRT
Output format of the encoded IP stream.
RTP requires an SDP file for the receiver that
corresponds to the video codec used.
TSRTP streams TS over RTP.
RTMP is only supported with H264(AVC) selected as
the Video Codec.
Dest Address
192.168.x.y
(192.168.0.6)
The IP address of the destination of the encoded
stream.
Dest Port
0 – 9999 (8600)
The destination port that the encoder is streaming
to.
Output Device
Click this field to select the detected storage
device for output file destination.
File Prefix
MOV1_%F_%T_
Textbox to enter desired file name for output file.
Entered
text will be followed by a number starting with
zero in the recorded file name.
%F will pull the current date, in year/month/day
format, into the file name.
%T will pull the current time, in 24-hour notation,
into the file name.
Max File Size
(1024M)
Sets the file size at which a new .ts file is started.
Video PID*
(UDP/TSRTP/TSFILE
Only)
0 – 8191 (221)
PID assigned to video in the TS stream.
PCR PID*
(UDP/TSRTP/TSFILE
Only)
0 – 8191 (521)
PID assigned to PCR in the TS stream.
PCR Interval*
(UDP/TSRTP/TSFILE
Only)
(50)
Interval assigned to PCR in the TS stream in
milliseconds.
PMT PID*
0 – 8191 (31)
PID assigned to PMT in the TS stream.
