Zebra TC70x Integrator Guide

CHAPTER 11 FIELD MEDIC
Introduction
Field Medic is the diagnostic application that allows easy collection of device information and Event Tracing for
Windows (ETW) logs right from the device. Field Medic saves the ETW log files and the general information in a
folder that is accessible using the USB Media Transfer Protocol (MTP).
Generating a Report
This section describes how to create a report.
Recording a Field Medic Report
To record device information in a Field Medic report:
1. Run the Field Medic app.
2. Touch Advanced.
3. Touch Choose which ETW providers to use.
4. Select the categories to include in the report.
NOTE MTP is enabled on all devices by default. It allows for the easy extraction of output files such as Field
Medic reports without requiring TShell or other test tools

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
