3 - 2 TC70x Integrator Guide
Figure 3-1 WEP WLAN Network Security Dialog Box
6. In the Password text box, enter the password.
7. Touch Done.
8. Touch .
Configuring a 802.1x Wi-Fi Network
Configure a Wi-Fi network using:
• User Name and Password
• Certificate.
User name and Password
To set up a Wi-Fi network using a user name and password:
1. Swipe down from the top of the screen, and touch All settings > Network & wireless > Wi-Fi.
2. Touch the Wi-Fi networking switch to turn on the Wi-Fi radio.
3. The device searches for WLANs in the area and lists them on the screen.
NOTE By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring for a
Proxy Server on page 3-5 for setting connection to a proxy server and see Configuring the Device to Use
a Static IP Address on page 3-6 for setting the device to use a static IP address.
