Page #155 background imageLoading...
Page #155 background image
CHAPTER 12 MAINTENANCE AND
TROUBLESHOOTING
Introduction
This chapter includes instructions on cleaning and storing the device, and provides troubleshooting solutions for
potential problems during operation.
Maintaining the TC70x
For trouble-free service, observe the following tips when using the TC70x:
Do not scratch the screen of the TC70x. When working with the TC70x, use the supplied stylus or
plastic-tipped pens intended for use with a touch-sensitive screen. Never use an actual pen or pencil or other
sharp object on the surface of the TC70x screen.
The touch-sensitive screen of the TC70x is glass. Do not to drop the TC70x or subject it to strong impact.
Protect the TC70x from temperature extremes. Do not leave it on the dashboard of a car on a hot day, and
keep it away from heat sources.
Do not store or use the TC70x in any location that is dusty, damp, or wet.
Use a soft lens cloth to clean the TC70x. If the surface of the TC70x screen becomes soiled, clean it with a
soft cloth moistened with a diluted window-cleaning solution.
Periodically replace the rechargeable battery to ensure maximum battery life and product performance.
Battery life depends on individual usage patterns.
Battery Safety Guidelines
The area in which the units are charged should be clear of debris and combustible materials or chemicals.
Particular care should be taken where the device is charged in a non commercial environment.
Follow battery usage, storage, and charging guidelines found in this guide.
Improper battery use may result in a fire, explosion, or other hazard.
To charge the mobile device battery, the battery and charger temperatures must be between +32°F and
+104°F (0°C and +40°C)

Table of Contents

Other manuals for Zebra TC70x

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra TC70x and is the answer not in the manual?

Zebra TC70x Specifications

General IconGeneral
Flash memory32 GB
Internal memory4 GB
Internal memory type-
Compatible memory cardsMicroSD (TransFlash)
Maximum memory card size128 GB
Display diagonal4.7 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Headphone outputs1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)-20 - 50 °C
Operating relative humidity (H-H)5 - 85 %
Battery voltage3.7 V
Battery capacity4620 mAh
Number of cores6
Processor model650
Processor familySnapdragon
Processor frequency1.8 GHz
Processor manufacturerQualcomm
Operating system installedAndroid
Product colorBlack
Linear (1D) barcodes supportedCode 39
International Protection (IP) codeIP67
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.1
Rear camera resolution (numeric)13 MP
SpeakersMono
Weight and Dimensions IconWeight and Dimensions
Depth28 mm
Width84 mm
Height161 mm
Weight376 g
