Zebra TC70x Integrator Guide

12 - 10TC70x Integrator Guide
5-Slot Ethernet Cradle Troubleshooting
4-Slot Battery Charger Troubleshooting
Table 12-5 Troubleshooting the 5-Slot Ethernet Cradle
Problem Cause Solution
During communication,
no data transmits, or
transmitted data was
incomplete.
TC70x removed
from cradle
during
communications
.
Replace TC70x in cradle and retransmit.
Incorrect cable
configuration.
Ensure that the correct cable configuration.
TC70x has no
active
connection.
An icon is visible in the status bar if a connection is currently active.
Battery is not charging. TC70x removed
from the cradle
too soon.
Replace the TC70x in the cradle. The battery fully charges in
approximately six hours.
Battery is faulty. Verify that other batteries charge properly. If so, replace the faulty
battery.
TC70x is not
inserted
correctly in the
cradle.
Remove the TC70x and reinsert it correctly. Verify charging is
active.
Ambient
temperature of
the cradle is too
warm.
Move the cradle to an area where the ambient temperature is
between -10°C (+14°F) and +60°C (+140°F).
Table 12-6 Troubleshooting the 4-Slot Battery Charger
Problem Cause Solution
Spare Battery Charging
LED does not light
when spare battery is
inserted.
Spare battery is
not correctly
seated.
Remove and re-insert the spare battery into the charging slot,
ensuring it is correctly seated.

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
