Power to Vehicle Cradle
The USB I/O Hub can provide power to a Vehicle Cradle.
1. Connect the Power Output Cable connector to the Power Input Cable connector of the Vehicle Cradle.
2. Tighten thumbscrews by hand until tight.
Figure 2-67 Power to Vehicle Cradle
Vehicle Cradle Power and
Communication Connector
Power and Communication
Connector
1
2
