Zebra TC70x Integrator Guide

Getting Started 1 - 5
• Charge Only Vehicle Cradle
• Auto Charging Cable Cup.
• Serial Cable Cup
The 4,620 mAh battery fully charges in approximately six hours at room temperature.
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The TC70x or accessory always performs
battery charging in a safe and intelligent manner. At higher temperatures (e.g. approximately +37°C (+98°F)) the
TC70x or accessory may for small periods of time alternately enable and disable battery charging to keep the
battery at acceptable temperatures. The TC70x or accessory indicates when charging is disabled due to abnormal
temperatures via its LED.
1. To charge the main battery, connect the charging accessory to the appropriate power source.
2. Insert the TC70x into a cradle or attach to a cable. The TC70x turns on and begins charging. The
Charging/Notification LED blinks amber while charging, then turns solid green when fully charged.
Charging Indicators
Replacing the Battery
1. Remove any accessory attached to the device.
2. Press the Power button until the menu appears.
3. Touch Battery Swap.
4. Follow the on-screen instructions.
Table 1-1 Charging/Notification LED Charging Indicators
State Indication
Off TC70x is not charging. TC70x is not inserted correctly in the cradle or connected
to a power source. Charger/cradle is not powered.
Slow Blinking Amber (1 blink
every 2 seconds)
TC70x is charging.
Solid Green Charging complete.
Fast Blinking Amber (2
blinks/second)
Charging error, e.g.:
Temperature is too low or too high.
Charging has gone on too long without completion (typically eight hours).
Slow Blinking Red (1 blink
every 2 seconds)
TC70x is charging but the battery is at end of useful life.
Solid Red Charging complete but the battery is at end of useful life.
Fast Blinking Red (2
blinks/second)
Charging error but the battery is at end of useful life., e.g.:
Temperature is too low or too high.
Charging has gone on too long without completion (typically eight hours).
CAUTION Do not add or remove SIM, SAM or microSD card during battery replacement.

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
