1 - 6 TC70x Integrator Guide
5. Wait for the LED to turn off.
6. If hand strap is attached, slide the hand strap clip up toward the top of the TC70x and then lift.
Figure 1-10 Remove Hand Strap Clip
7. Press the two battery latches in.
Figure 1-11 Press Battery Latches
8. Lift the battery from the TC70x.
