2 - 8 TC70x Integrator Guide
2-Slot USB/Ethernet Cradle
The 2-Slot USB/Ethernet Cradle:
• Provides 5.0 VDC power for operating the device.
• Charges the device’s battery.
• Charges a spare battery.
• Connects the device to an Ethernet network.
• Provides communication to a host computer using a USB cable.
Figure 2-5 2-Slot USB/Ethernet Cradle
NOTE Remove all attachments on the device, except the hand strap, before place onto the cradle.
Spare Battery Charging LE
Power LED
