Zebra TC70x Integrator Guide

Technical Specifications A - 3
Operating Channels Chan 1 - 11 (2412 - 2422 MHz) - North America (FCC and IC)
Chan 1 - 13 (2412 - 2472 MHz) - Rest of the World
Chan 36 - 165 (5180 - 5825 MHz)
Channel Bandwidth: 20, 80 MHz
Actual operating channels/frequencies depend on regulatory rules and
certification agency
Security WEP (40 or 104 bit)
WPA/WPA2 Personal (TKIP, and AES)
WPA/WPA2 Enterprise (TKIP, and AES) — EAPTTLS (PAP, MSCHAP,
MSCHAPv2), EAP-TLS, PE APv0-MSCHAPv2, PE APv1-EAP-GTC,EAP Fast
and LEAP
FIPS DIM4
Voice Communications Voice-over-IP ready, Wi-Fi™-certified, IEEE 802.11a/b/g/n direct sequence
wireless LAN, Wi-Fi Multimedia™ (WMM)
Wireless PAN Data and Voice Communications
Bluetooth Bluetooth v4.1 Low Energy
Data Capture Specifications
2D Imager SE4750-SR – 1D and 2D bar codes.
Camera
Rear: 8 Mega pixel auto focus; f/2.4 aperture
Front: 1.3 Mega pixel fixed focus
Near Field Communications
(NFC)
ISO 14443 Type A, B and F, FeliCa, and ISO 15963 cards. Secure NFC via
SAM supporting Mifare, Calypso and FeliCa. P2P mode and Card Emulation via
UICC and Host.
2D Imager Engine (SE4750-SR) Specifications
Field of View Horizontal - 48.0°
Vertical - 36.7°
Image Resolution 1280 horizontal X 960 vertical pixels
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,639 lux)
Table A-1 TC70x Technical Specifications (Continued)
Item Description

Zebra TC70x Specifications

General

Flash memory	32 GB
Internal memory	4 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Display diagonal	4.7 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 85 %
Battery voltage	3.7 V
Battery capacity	4620 mAh
Number of cores	6
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Product color	Black
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Rear camera resolution (numeric)	13 MP
Speakers	Mono

Weight and Dimensions

Depth	28 mm
Width	84 mm
Height	161 mm
Weight	376 g
