74 Z4Mplus and Z6Mplus User Guide
Configuration
Configuration and Calibration Sequence
COMMUNICATIONS Press SELECT to make change.
Setting Communications Mode: Press PLUS (+) or
MINUS (–) to display other choices.
Default: Normal mode
Selections: Normal mode, diagnostics
Press SELECT to accept the change.
The communication diagnostics mode is a troubleshooting
tool for checking the interconnection between the printer and
the host computer. When “diagnostics” is selected, all data
sent from the host computer to the printer is printed as
straight ASCII hex characters. The printer prints all
characters received including control codes, like CR
(carriage return). A sample printout is shown on page 112.
Notes • on diagnostic printouts:
FE indicates a framing error.
OE indicates an overrun error.
PE indicates a parity error.
NE indicates noise.
For any errors, check that your communication parameters
are correct. Set the print width equal to or less than the label
width used for the test. See page 65 for more information.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
