EQUIPMENT DESCRIPTION
Axio Examiner Technical data Carl Zeiss
M60-2-0003 e 05/2012 25
Mercury vapor short arc lamp............................................................................................. HBO 103 W/2
Power consumption for HBO 103 W/2 ...................................................................................... 100 W
Colibri illumination system
Power consumption .................................................................................................................. 70 VA
Examiner control:
Field of application ....................................................................................................................... indoor
Safety class .............................................................................................................................................I
Degree of protection ....................................................................................................................... IP 20
Line voltage ............................................................................................ 100 … 127 V / 200 … 240 VAC
No line voltage adjustment is required.
Power frequency................................................................................................................... 50 to 60 Hz
Power consumption ..................................................................................................................... 260 VA
Optical and mechanical data:
Stand with manual objective focusing
Coarse adjustment ................................................................................................. 2 mm / revolution
Fine adjustment ................................................................... 0.2 mm / revolution; 0.2 µm scale interval
Maximum stroke range ............................................................................................................15 mm
Height stop ..................................................................................................... mechanically adjustable
Condenser.......................................................................................... achromatic-aplanatic 0.9 H DIC, 5x
......................................................................... for bright field, dark field, phase contrast 1, 2, 3 and DIC
Manual objective exchange ............................................... using an objective mount, 2x, M27, DIC coded
.................................................................. using a four-position objective nosepiece 4x, M27, DIC coded
Manual reflector module exchange .................................................................... using a 2x reflector slider
.................................................................................................................... Reflector turret, 4x, 5x or 6x
Stand with motor-driven objective focusing
Stroke ..........................................................................................................................................15 mm
Focusing ............................................................................................. using motor controller and keypad
Focusing speed ............................................................................................................................ variable
Limit switch for operating range ........................................................................... electronically adjustable
Approach of stored focus positions ................................................................... up to 5 storable positions
Defined moving in and out of the last working position ..................................... using the home function
Focusing in defined steps .................................................................................smallest increment: 25 nm
