OPERATION
Carl Zeiss Docking station with TFT display Axio Examiner
78 M60-2-0003 e 05/2012
(5) Language
In this tab, the user may select the language for the TFT display. German and English are available for
selection so far. Modifications to the basic setting will be applied after an automatic restart of the
equipment.
Tools 4.3.6.3
The Settings -> Tools page contains the Ethernet and Miscellaneous tabs.
(1) Ethernet
This tab allows settings for connecting the Axio Examiner via Ethernet.
(2) Miscellaneous
This tab enables the operator to calibrate the touch screen display.
About 4.3.6.4
The Settings -> About page only contains the Firmware tab.
This tab indicates the firmware version to the operator.
4.3.7 Display
Press the Display button in the navigation bar on the Home page to open the Display page. To darken
the TFT display, keep the Display button in the navigation bar pressed for more than a second. To switch
on the TFT display again, just touch any point on the display.
You may use the Display page to customize the brightness of the TFT display by pressing the ◄►
buttons.
Press the Display off button to switch the TFT display off. Touch this button again to switch the TFT
display on again.
After switching out, the TFT display returns from the Display page to the previous page from
which it was opened. The latter will be displayed when switched on again.
