START-UP
Axio Examiner Installing standard components Carl Zeiss
M60-2-0003 e 05/2012 45
• Turn the knurled knob (Figure 3-28/4) to focus the brighter focal spot using the collector adjustment.
• Turn the adjusting screws (Figure 3-28/2 and 3) to set the darker focal spot (burner mirror image) by
analogy to the focal spot image (Figure 3-27/2) within the inscribed adjusting circle.
The two focal spots of the HBO 103 W/2 lamp should be located close to one another within the
adjusting aid's adjusting circle.
• Screw the objective in again.
3.1.16 Colibri illumination system and HXP 120 external illumination equipment
Connect and start up the Colibri and HXP 120 as described in the separate operating manual for the
Colibri illumination system.
