OPERATION
Axio Examiner Controls and functional elements for optional components Carl Zeiss
M60-2-0003 e 05/2012 81
• Unscrew the knurled screw (Figure 4-22/1) at the camera port on the rear side.
• To adjust the camera in X and Y direction, turn the two adjusting screws (width A/F 1.5) (Figure 4-22/2
and 5).
• Tighten the knurled screw (Figure 4-22/1) at the camera port on the rear side again.
