Engaging rear PTO shaft - Independent revolutions
C15N017
The number of PTO shaft revolutions is dependent on the number of engine revolutions.
With engine running:
1. Select applicable operation mode PTO shaft revolutions preselection lever.
2. Select applicable revolutions by switch of selection of rear PTO shaft (2) revolutions.
3. Rear PTO shaft is set into operation by switching the switch of rear PTO shaft (3).
Engagement of rear PTO shaft is signalized by the display of the number of rear PTO shaft revolutions on
the display of the dashboard.
If the aggregated machine allows it, engage the rear PTO shaft with minimum revolutions of
1500 rpm.
Engagement of rear PTO shaft - dependent revolutions
C15N18
The number and the direction of the revolutions are dependent on the engaged gear and the position of
reversing lever. The position of reduction lever does not have any influence on the number rear PTO shaft
revolutions in dependent revolution mode.
With engine running:
1. Rear PTO shaft dependent revolutions are selected by PTO shaft revolutions preselection lever.
2. Rear PTO shaft switch (3) is not functional in this mode.
3. Select applicable revolutions by rear PTO shaft selection switch (2).
4. Engage gear by the main gear shifting lever and the direction of drive by reversing lever. When tractor
drives off, rear PTO shaft also spins.
Automatic PTO clutch disengagement is not functional in this mode.
DRIVE OF AGRICULTURAL MACHINERY
