Rear window
Side window
Hinged lid
Adjustable screen and cover of the swing lid
Is equipped with a handle and in an open position is
locked by gas spruts. Rear window is heated.
When driving on an uneven surface we
recommend to secure the window in a closed position
- danger of window cracking. Before starting the work
with the machinery Before starting the work with
mounted in three-point hitch of the tractor, make sure
that there is not a danger of collision between the
mounted tools with maximum lifting of rear three-
oint hitch and open rear window. In case of collision
we recommend to work with a closed window.
C15N025
The window is secured in the partly open position with
a plastic latch. You can open the door by lifting the latch
towards yourself upwards and pushing it into the groove.
Then, the window will be secured in the fixed position.
F25
It is opened by turning the locking lever of the cover (1)
and by pressing the locking lever in the upward direction.
The swing cover is closed with the opposite procedure.
By opening of the swing cover, the total height
of the tractor is increased. Therefore always close the
cover when driving through or parking in places with
a reduced internal diameter.
C15N026
Pull out the adjustable screen of the front window (1) by
pulling the hand rail in the arrow direction.
To return to the original position, shortly pull the hand rail
in the direction of the arrow and release the hand rail.
The sliding cover of the swing lid (2) is closed and opened
with pressure or by pulling the slots in the arrow direction
C15N146
ACQUAINTANCE WITH THE TRACTOR
