Reversing lever position signalizatio
Shifting road and reduced speeds
Road and reducing speeds lever position signalization
Driver´s seat - safety switch
The individual positions of reversing lever are signalized
by a sign (1) on the display.
driving forward
Neutral
driving backward
C15N063
Shifting the gears of the main gearbox with reduced
speeds is the same as with road speeds.
Road and reduced speeds shifting lever can be
shifted only with a tractor at standstill.
H - Road speeds
N - Neutral
L - Reduced speeds
F72
The individual positions of road and reduced speeds lever
are signalized by a sign (1) in the left bottom corner of the
display.
road speeds
neutral position
reduced speeds
C15N064
The driver´s seat is equipped with a safety switch which
signalizes the system of driver abandoning the driver´s
seat.
If the tractor is started, there is nobody on the driver´s sea
and reversing lever under the steering wheel is shifted to
F or R position, N position is shifted automatically and
tractor does not start.
If this situation occurs, it is necessary to sit on the driver´s
seat, to return the reversing lever under the steering wheel
to N position and then to select the direction of drive again
(F or R).
