The average speed and the fuel consumption of the tracto
r
C15N153
Average speed of the tractor
The average speed of the tractor (1) in km/h from the last reset of the data is displayed on the display.
If you want to determine the average speed for a certain period, you must reset (zero) the value at the
beginning of the measurement.
After the reset, 0 is displayed during first 100 m on the display, then the value is updated every 10 s or 100
m of the distance travelled.
Average consumption of the fuel
The average consumption of the fuel (2) in litres per hour from the last reset of the data is displayed on the
display (2). If you want to determine the average consumption for a certain period, you must reset (zero) the
value at the beginning of the measurement. The value is updated every 10 s.
Manual zeroing (reset) of data
Except automatic zeroing of data, these entries can be zeroed manually.
For manual zeroing of data, the tractor must be with the engine not started and with the key of the switch box
in the position I.
Select display of the corresponding main screen using the button (F).
Zero the entry by longer pressing of the button (E) (RESET).
Attention! Both entries are always zeroed simultaneously; a single entry cannot be zeroed.
Display - resetting data
The procedure for zeroing data in the secondary field at the main screens where the data can be zeroed is
as follows:
1 - Select display of the corresponding main screen using button (F).
2 - Zero the entry by longer pressing of button (E) (RESET).
C15N055
DASHBOARD
49
