Main tractor's parameters (mm)
Technical data of engines
Note
Position length with the suspension
device with lowered front TPL
5,130
without additional
weights
Position length with the suspension
device with front TPL
4,605
without additional
weights
Width over rear mudguards 2,330
Height to the exhaust muzzle 2,875-2,970
according to the tyre
dimensions
Height of the tractor to the cabin upper
edge
2,815-2,910
according to the tyre
dimensions
Clear height under the front axle beam 515-570
according to the tyre
dimensions
Height of the flat mouthpiece in the
highest position (centre of the
mouthpiece)
1,000
Wheelbase 2,840
Tractor type Crystal 150 Crystal 160
Engine type TCD6.1L6
C4ST106A
TCD6.1L6
C4ST120
Engine design serial, standing, water cooled
Engine type diesel, for-stroke with direct fuel injection,
turbocharged with cooling of filling air
Injection system Common rail
Additional treatment of exhaust gases Selective catalytic reduction (SCR)
Number of cylinders 6
Cylinder capacity
cm
3
6,057
Bore x stroke mm 101x126
Rated speed
min
-1
2,100
Idle speed
min
-1
700
Injection order 1-5-3-6-2-4
Engine pressure ratio 18
Max. power / engine revolutions (EC 24) kW / rpm 106.5/1,800 120.1/1,800
Specific fuel consumption at 2,100 rpm g.kW.h 233.2 226.3
Max. torque / engine revolutions Nm / rpm 664/1,500 738.9/1,500
Torque reinforcement % 37.67 35.08
Minimum oil pressure at engine idle and oil
temperature of 80°C
MPa 0.08
Max. temperature of cooling liquid °C 110
MAIN TECHNICAL PARAMETERS
