Zetor CRYSTAL Series User Manual

Front tires steerabilit
y
Tyre
dimensions
Travelling speed
40 km.h
-1
30 km.h
-1
20 km.h
-1
Tyreload-
bearing
capacity
(kg)
Tyreload-
bearing
capacity
(kg)
Tyreload-
bearing
capacity
(kg)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
480/70 R24 2100 4200 120 2100 4200 110 2100 4200 90
420/70R28 2060 4120 160 2100 4200 145 2100 4200 120
480/65 R24 2100 4200 140 2100 4200 130 2100 4200 105
540/65 R24 2100 4200 100 2100 4200 90 2100 4200 75
480/65 R28 2100 4200 125 2100 4200 115 2100 4200 95
14,9R24 1950 3900 160 2090 4180 160 2100 4200 155
420/70R24 1900 3800 160 2030 4060 160 2100 4200 145
The specified inflation values are minimum valued adapted to the current tyre load so that the tyre
deformation can remain in the range in which all the operation requirements are met.
Change of the load-bearing capacity of the front tyres (%)
Tyre
dimensions
Travelling speed
8 km.h
-1
6 km.h
-1
Tyreload-bearing
capacity
(kg)
Tyreload-bearing
capacity
(kg)
Tyre
1 pc
Axle Inflation
(kPa)
Tyre
1 pc
Axle Inflation
(kPa)
480/70 R24 2600 5200 125 3000 6000 140
420/70R28 2600 5200 150 3000 6000 200
480/65 R24 2600 5200 135 3000 6000 165
540/65 R24 2600 5200 95 3000 6000 125
480/65 R28 2600 5200 120 3000 6000 150
14,9R24 2600 5200 165 2925 5850 200
420/70R24 2600 5200 180 2850 5700 200
Travelling speed (km/h) diagonal radial
8 + 40 + 50
20 + 20 + 23
30 0 + 7
0 - 20 0
MAIN TECHNICAL PARAMETERS
169

Zetor CRYSTAL Series Specifications

General

Transmission	Mechanical or PowerShift
Aspiration	Turbocharged
Hydraulic System	Load Sensing (LS)
Cylinders	6
Hydraulic System Type	Load Sensing (LS)
PTO Speed	540/1000 rpm
Weight Approx	3, 800-5, 500 kg
