Direction lights, lower beam head lights, head lights and horn switches
When the signal lamps are turned on, the acoustics signal is activated.
Switch box
Switch box key in the position (0)
a - Acoustic horn - press the switch in the direction of an
axis
b - Lower beam head lights
c - Direction lights to the right
d - Direction lights to the left
e - Acoustic horn
f - Lower beam headlights
X139
Switchbox is placed on the dashboard, see arrow
.
C15N053
The voltage of all the equipment controlled via the key is
disconnected. The key can be removed.
S43
ACQUAINTANCE WITH THE TRACTOR
32
