Road and reduced speeds shifting leve
r
PTO revolutions preselection lever
Manual brake lever and coupling for semi-trailer control lever
The lever is placed on the right side of driver´s seat.
H - Road speeds
N - Neutral
L - Reduced speeds
F72
The lever (1) is placed on the right side of driver's seat.
For more information see the chapter on Drive of
agricultural machines.
1 - manual brake lever
a - unbraked
b - braked
2 - coupling for semi-trailer lever
a - transporting position
b - bearing hooks folded up; tow hook with carrier can be
started
F74
ACQUAINTANCE WITH THE TRACTOR
35

Zetor CRYSTAL Series Specifications

General

Transmission	Mechanical or PowerShift
Aspiration	Turbocharged
Hydraulic System	Load Sensing (LS)
Cylinders	6
Hydraulic System Type	Load Sensing (LS)
PTO Speed	540/1000 rpm
Weight Approx	3, 800-5, 500 kg
