Front PTO shaft control
Maximum transferred output
Engagement and disengagement of front PTO shaft is
done by a switch (4) The switch is equipped with
a mechanical lock (2) against unwanted switch. When
switching the switch depress the lock in the downward
direction.
Front PTO shaft is set into activity by switch of a switch.
C15N022
The engagement of front PTO shaft is signalized by
displaying the number of revolutions of front PTO shaft on
the display of dashboard.
If the aggregated machine permits, engage
front PTO shaft with min. engine revolutions of 1500
rpm.
C15N147
PTO shaft Transferred output
Front
1000 per minute 90 kW
Rear
1000 per minute full engine output
540 per minute full engine output
1000E per minute 60 kW
540E per minute 60 kW
F_02_46
DRIVE OF AGRICULTURAL MACHINERY
