Drive of machines with greater inertia masses

(crushers, rotary harrows, reaping machines, etc.)

Cardan shaft for drive of these machines must be

equipped with the so called freewheel clutch which

ensures disconnection of torque transfer with retroaction

from the machine on the tractor.
