Fuel tank
Fuel tank drain plug
Urea tank
Add only urea!
Other media, even a small amount (e.g. diesel oil), lead to the destruction of the system.
If e.g. diesel oil was loaded and is present in the system, the whole system of urea injection must be
replaced!
If the loaded medium (e.g. diesel oil) does not reach the guide or export pump I of the dosing module,
all you have to do is to empty and thoroughly clean urea tanks.
Maintain cleanliness.
plastic tank of 300 litres volume is mounted as
a standard for all types of tractors.
Do not step on the fuel tank!
C15N133
Plug for draining dirt and fuel off the fuel tank is in its
bottom.
H800
The tank for urea is located in the left side of the tractor
and is equipped with the blue plug of the filling hole.
The tank volume is 32 litres.
C15N075
ACQUAINTANCE WITH THE TRACTOR
