Zetor CRYSTAL Series User Manual

Lifting force of the three-point hitc
h
Tensile force
Lifting force at the end of the bottom
draw-bars of the rear three-point hitch in
the whole lifting range at the maximum
usable pressure (kN).
76
Lifting force at the end of the lower draw-
bars of the front three-point hitch in the
whole lifting range at the maximum
usable pressure (kN) - Zuidberg front
three-point hitch
35
Traktor type Crystal 150 Crystal 160
Engine type (TIER III B) TCD6.1L6 C4ST106A TCD6.1L6 C4ST120
Maximum tensile force (kN) in swinging
draw bar on concrete, tractor in emergency
finish with ballast weights, with slippage to
15%
53 54
MAIN TECHNICAL PARAMETERS
171

Zetor CRYSTAL Series Specifications

General

Transmission	Mechanical or PowerShift
Aspiration	Turbocharged
Hydraulic System	Load Sensing (LS)
Cylinders	6
Hydraulic System Type	Load Sensing (LS)
PTO Speed	540/1000 rpm
Weight Approx	3, 800-5, 500 kg
