Pos.. Fuse size Secured system
F1 15A brake lights, tripper of warning lights
F2 15A horn, beacon
F3 15A appliances fed when key is in position I
F4 15A distance lights with signal lamp
F5 10A left position lights, instrument panel lighting, number
plate lighting
F6 10A right position lights
F7 15A right dimmed lights, fog-lamp with signal lamp
F8 7,5A left dimmed lights
F9 15A Front work lights in engine bonnet
F10 3A front PTO shaft
F11 15A front and rear windshield, windshield washer
F12 15A radio, dome light
F13 15A Firer, two-pole socket
F14 7,5A air-conditioning
F15 10A heating of mirrors
F16 10A heating of rear window
F17 15A compresor of driver´s seat
F18 20A three-pin socket DIN 9680
F19 15A work lights under the roof
F20 15A work lights under the roof
F24 15A ECU power supply of gearbox
F25 7,5A EHR
F26 7,5A EHR
F27 unoccupied
F28 7,5A spring-loaded front axle
F29 10A tripper of direction lights
F31 15A SCR system
F32 10A turbo-blower
F33 unoccupied
F34 unoccupied
F35 15A Rear work lights on the cabin
F36 10A diagnostic socket, instrument panel
F37 unoccupied
F38 unoccupied
F51 30A heating
F52 30A engine control with electronic regulation of revolutions
F53 30A heating of urea
