Note: The 380/70R24 tyre is a dimensional equivalent of the 13.6R24 tyre.
The 420/70R24 tyre is a dimensional equivalent of the 14.9R24 tyre.
The specified load-bearing capacities of tyres for field work and road transport correspond to the maximum
travelling speed of the tractor, i.e. in the case of radial tyres 40 km/h and in the case of diagonal tyres 30
km/h. The specified val-ues refer to one tyre. For a tractor the max. load per axle must not exceed the max.
load-bearing capacity values of the tyres.
Recommended inflation values of the rear wheel tyres
The value of the permitted load-bearing capacity of the rear axle must not exceed the sum of the load-
bearing capacity values of both the tyres that are installed on the axle. The values of the permitted load-
bearing capacity of the axles are specified in the 'Main technical parameters' of the corresponding tractor
type. On the same axle of the tractor there must not be tyres of different dimensions and designs (in this
case tyre design means the diagonal or radial tyre version).
Tyredimensions and design
Principal working
activity
540/65 R24 480/65 R28 14,9R24 420/70R24
For field work Inflation (kPa) 130-160 130-160 130-160 130-170
Load-bearing capacity
(kg)
2410-2725 2150-2430 1490-1700 1665-1900
For road transport Inflation (kPa) 160-190 160-190 130-160 190
Load-bearing capacity
(kg)
2410-2725 2150-2430 1490-1700 1665-1900
For work with a front
loader at the
maximum permitted
speed of 8 km/h.
Inflation (kPa) 200 200 200 200
Load-bearing capacity
(kg)
4105 3680 2500 2300
Tyredimensions and design
Principal
working
activity
650/65R38 600/65R38 18,4R38 520/70R38 580/70R38
For field work Inflation (kPa) 130-160 130-160 130-160 110-160 130-160
Load-bearing
capacity (kg)
3620-4125 3200-3650 2625-3000 2635-3350 3475-3880
For road
transport
Inflation (kPa) 160-190 160-190 130-160 110-160 160-190
Load-bearing
capacity (kg)
3620-4125 3200-3650 2625-3000 2635-3350 3475-3880
