TROUBLESHOOTING
Page 9
AT THE NEUTRAL/IDLE POSITION REGARDLESS OF THE CONTROL
HEAD LEVER POSITION.
Cause:
The Processor is in the Set-up Mode and an adjustment setting is
selected.
Remedy:
Configure the Processor into the Run State by placing Jumper 2 in the
Open State and SW1-1 through SW1-7 to the Off positions. Refer
to the Run State Section of the manual.
1.17
SYMPTOM - SET-UP MODE IS ENTERED AND THE NORMAL 3 SECOND
STEADY TONE IS HEARD. THE MOTOR CONTROL RELAY “CLICKS”
CONTINUOUSLY WHEN THE DIP SWITCHES ARE TURNED ON.
Cause:
An invalid switch combination is selected.
Remedy:
Turn SW1-1 through SW1-7 to the Off positions. Refer to the Notes
page of the System Drawing in Appendix C for proper switch settings.
1.18
SYMPTOM - THE MOTOR RELAY DOES NOT CLICK ONCE, INDICATING
VALUES HAVE BEEN STORED, WHEN PB1 ON THE AUXILIARY CIRCUIT
IS DEPRESSED.
Cause:
Each Step in the Set-up & Adjustment Sections of the Technical Man-
ual were not followed exactly.
Remedy:
Repeat the set-up or adjustment following each step exactly.
