ZOLL X Series User Manual

Chapter 7 Monitoring Respiration (Resp) and Heart Rate (HR)
7-6 www.zoll.com 9650-001355-01 Rev. M
Heart Rate (HR/PR) Alarm Limits
Initially, the HR/PR Alarm Settings menu specifies that alarms are enabled (ON) or disabled
(
OFF), and displays the default Upper and Lower heart rate alarm limits. The upper and lower
limits can be
ON or OFF (default is OFF). The following table lists the default HR alarm limits
for adult, pediatric, and neonate patients, and gives the range in which you can set these limits:
Patient Type HR Default HR Range
Adult Lower: 50 BPM
Upper: 120 BPM
Lower: 30 to 298 BPM
Upper: 32 to 300 BPM
Pediatric Lower: 50 BPM
Upper: 150 BPM
Lower: 30 to 298 BPM
Upper: 32 to 300 BPM
Neonate Lower: 100 BPM
Upper: 200 BPM
Lower: 30 to 298 BPM
Upper: 32 to 300 BPM

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
