Treatment Summary Report
9650-001355-01 Rev. M X Series Operator’s Guide 21-3
Reviewing and printing snapshots
You can perform this procedure from any main display screen.
1. Press the Home/Display button ( ) repeatedly until the Trends window displays.
2. Use the navigation keys to get to the Trends window.
3. Press the Select button to scroll through the list of trends.
Note: The snapshots have a snapshot icon next to the time stamp.
4. Select the desired snapshot from the Trends list and press Select. The snapshot numeric data
displays.
5. To print the data and the snapshot waveforms, highlight Print this Snapshot and press
Select.
Note: If you attempt to print a snapshot before the unit has finished storing the snapshot in
the log, a NO DATA AVAILABLE message is printed. To print the snapshot correctly,
wait until the snapshot is complete, then select and print it again.
Treatment Summary Report
The Treatment Summary Report is a report that shows all of the treatment events related to a
patient such as defibrillation/pacer events, alarm events, and treatment snapshots. It is helpful
to print out this report at the end of a case.
Printing Treatment Summary Report
To print a treatment summary report, do the following:
1. Press the More quick access key ( ).
2. Press the Log quick access key ( ).
3. Press the Treatment Summary quick access key ( ). The Treatment Summary window
displays.
4. Use the navigation keys to highlight and select the treatment summary you want to print.
Note: The Treatment Summary Report that you selected has a check mark next to it.
5. Use the navigation keys to highlight and select Print Treatment Summary.
TREATMENT SUMARY REPORT
Name: Phillip Davies 06:06:14 New Case ID
ID: Patient 0015 Patient Mode: Adult 06:06:14 System On
Start Time: 06/06/11 06:06:14 06:06:14 Patient Mode Adult
Last Event: 06/06/11 09:43:40 06:06:14 Some Alarm Limits
Disabled
Elapsed Time: 00:29:48 # Events: 06:06:20 Self Test Passed
Total Shocks: 1 06:06:43 Treatment Snapshot: ASA
Total Pace
Time: 00:00:00
Total 12 Leads: 0
Dept: ICU
Unit:
S/N: 0 SW: 00.00.00.00
LOG

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
