Configuring NIBP Alarms and Settings
9650-001355-01 Rev. M X Series Operator’s Guide 8-13
Using the NIBP Parameter Control Panel
Use the navigation keys to highlight and select the NIBP numeric display to display the NIBP
Parameter Control Panel:
Figure 8-4 NIBP Parameter Control Menu
On the NIBP Parameter Control Panel, you can select an alarm configuration option (SYS, DIA,
or
MAP) to enable/disable alarms and set high and low alarm limits (as described previously).
You can also configure these NIBP options:
• NIBP Mode (Mode)
• NIBP Automatic Measurement Interval (Auto Interval)
• Enable/Disable Smartcuf motion artifact filter (Smartcuf)
•
Start/Stop Turbocuf Measurements (Turbocuf)
Specify NIBP Mode
You can specify that the X Series unit operate in either Manual or Automatic Mode.
In Manual Mode, the X Series unit takes a single NIBP measurement when you press the NIBP
button on the front panel( ). To repeat the NIBP measurement, you must press the NIBP key
again (select
Manual).
In Automatic Mode, the X Series unit takes the first of a series of NIBP measurements when
the
Auto Interval timer expires, and then repeats the NIBP measurement at this specified
interval.
Note: You can press the NIBP button and manually initiate an NIBP reading at any time
while in Automatic Mode. Manually initiated NIBP readings will not affect the timing
of subsequent NIBP readings in Automatic Mode.
Specify the Automatic NIBP Measurement Interval
You can specify the time interval between NIBP measurements in Automatic Mode. The
default interval between measurements is 5 minutes.
You can specify intervals of
1, 2, 3, 5, 10, 15, 30, and 60 minutes between NIBP measurements.
NIBP
Lower Upper
NIBP Systolic Alarm 75
220
NIBP Mode Manual
NIBP Auto Mode Interval 5 min
NIBP Diastolic Alarm 35
110
NIBP MAP Alarm 50
120
Start TurboCuf
SmartCuf On/Off
On
59
50 100
150
200 250 300
