ZOLL X Series User Manual

Chapter 11 Monitoring Invasive Pressures (IBP)
11-6 www.zoll.com 9650-001355-01 Rev. M
Enabling/Disabling IBP Alarms and Setting Alarm Limits
When enabled, the X Series unit sounds alarms whenever IBP measurements are outside set
limits for the following:
• High and Low Systolic Pressure
• High and Low Diastolic Pressure
• High and Low Mean Arterial Pressure (MEAN)
Note: When enabled, any of the low alarms for IBP (systolic, diastolic, or mean) will also
provide an alert in the event of a disconnected catheter.
To enable (or disable) IBP alarms and set Upper and Lower alarm limits and IBP channel, you
can either use the navigation buttons to highlight and select the IBP channel display or:
1. Press the More quick access key ( ).
2. Press .
3. Press the Limits quick access key ( ).
4. Use the navigation buttons to highlight and select the appropriate alarm menu selection. For
each IBP channel, there are alarm menus for systolic (Systolic Alarm), diastolic (Diastolic
Alarm) and mean arterial pressure (Mean Alarm) alarm settings. On the selected Alarm
Settings menu, use the navigation keys to select the fields that you want to change. The fields
are
• Upper Limit Enable
• Lower Limit Enable
• Upper Limit
• Lower Limit
5. When you are finished changing values on the alarm menu, navigate to the Backarrow key
to exit the menu.
Setting Upper and Lower Systolic (SYS) Alarm Limits
Initially, the IBP Systolic Alarm Settings menu specifies that the IBP systolic pressure alarms
are enabled (
ON) or disabled (OFF), and displays the default upper and lower systolic limits.
The upper and lower limits can be
ON or OFF (default is OFF). The following table lists the
default IBP Systolic limits for adult, pediatric, and neonate patients, and gives the range in
which you can set these limits:
Limits
Patient Type IBP Systolic Limit Default IBP Systolic Limit Range
Adult Lower: 75 mmHg
Upper: 220 mmHg
Lower: -30 to 298 mmHg
Upper: -28 to 300 mmHg
Pediatric Lower: 75 mmHg
Upper: 145 mmHg
Lower: -30 to 298 mmHg
Upper: -28 to 300 mmHg
Neonate Lower: 50 mmHg
Upper: 100 mmHg
Lower: -30 to 298 mmHg
Upper: -28 to 300 mmHg

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
