Attaching the Invasive Pressure Transducer
9650-001355-01 Rev. M X Series Operator’s Guide 11-3
Attaching the Invasive Pressure Transducer
Follow these steps when attaching the invasive pressure transducer:
1. Inspect the transducer cable. If the cable shows any signs of wear, breakage, or fraying,
replace the cable. Replace the transducer dome, if necessary.
2. Apply the transducer according to your organization’s procedures. Always refer the
manufacturer’s Directions for Use before using a transducer.
3. If the transducer is a disposable unit with a separate cable, connect the transducer to the
transducer cable.
4. Plug the transducer cable into one of the three six-pin IBP cable connectors on the side of the
X Series unit.
Figure 11-1 Plugging the Transducer into the X Series
When you plug the transducer cable into the unit, the message ZERO PROBE appears in the
numeric display window for that IBP channel.

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
